UV Machine

SPECIFICATION:

• Appearance : Black grey + medium grey
• Print: Ricoh GEN5i/i3200u/XP600(1-4)
• Rail : Double rail
• Color : CMYK+Lc+Lm+White+Varnish
• Flat bed size(mm) : 940 x 640
• Print Thickness(mm) : Plate printing thickness0.1mm-380mm Cylinder print diameter 20mm-200mm (Ultra-high customizable)
• Curing System : LED UV Lights
• Image Format : TIFF/JPG/EPS/PDF/BMP
• Rip Software : PHOTOPRINT/Maintop/Riin Rip-honson
• Negative pressure : White and color separate negative pressure
• Power Supply : AC220V 50HZ ±10%
• Temperature : 20-32°C
• Humidity : 40-75%
• Power : 2500W
• Appearance Size (mm) : Length/width/height:2065/1180/1005
• Data Transmission : TCP/IP network interface
• Net Weight(kg) : 400
• Wooden box size(mm) : 2520X1550X1410
• Suction system : 750W brand fans
• Y-axis : Servo motor drive
• Lead screw : Imported brand double Y screw
• Automatic height measurement : The system drives the automatic height measurement function
